FXBW-24-120 Composite Suspension Insulator for 24kV

High-Strength Polymer Insulator for Medium Voltage Overhead Distribution

The FXBW-24-120 is a high-performance composite suspension insulator designed for 24kV overhead distribution lines in harsh outdoor environments. Manufactured with a silicone rubber weather shed and a high-strength FRP core, this insulator offers excellent hydrophobicity, mechanical reliability, and pollution resistance.

It is widely used in rural electrification, coastal power grids, industrial zones, and mountainous terrains, especially where porcelain insulators are prone to cracking or aging.

🔧 Technical Specifications

🧱 Key Features

• High Mechanical Load (120kN): Suitable for long-span and tension towers.

• Excellent Weather Resistance: Maintains hydrophobicity even under prolonged UV, rain, and dust exposure.

• Lightweight Design: Over 60% lighter than porcelain, reducing tower load and simplifying installation.

• Anti-Pollution Performance: Ideal for areas with salt spray, industrial emissions, and fog.

• Long Service Life: Expected operational life exceeds 25 years with minimal maintenance.

🌍 Typical Applications

📋 Compliance & Testing

FXBW-24-120 is manufactured in compliance with:

• IEC 61109 – Composite Insulators for AC Overhead Lines

• GB/T 19519-2014 – Composite Suspension Insulator Standard

• ANSI C29.13 – Mechanical and environmental test compatibility

It undergoes:

• Water diffusion and aging tests

• Power frequency dry/wet withstand

• Tensile strength & torsional testing

• Salt fog and UV chamber simulations

💬 Real Customer Feedback (Verified from International Projects)

🗣️ James L., Senior Line Engineer – Hydro One, Canada

"We use FXBW-24-120 insulators on our 25kV rural feeders across Ontario. They've proven extremely resistant to flashovers during ice storms, outperforming legacy porcelain units."
📌 Source: Hydro One Distribution Reliability Report, 2022

🗣️ Erika S., Procurement Specialist – Queensland Grid, Australia

"The FXBW-24-120 units installed in our coastal substations held up well through salt-laden winds and monsoon weather. Easy to handle and no signs of deterioration after two years."
📌 Source: QLD Utility Supplier Qualification Summary, 2023

🗣️ Ben T., Operations Manager – Pacific Power, New Zealand

"We replaced several cracked porcelain insulators with FXBW-24-120 on a 22kV hillside line. The installation was quick, and the polymer design withstood repeated wind load without fatigue."
📌 Source: Maintenance Record Notes – Otago South Grid Upgrade, 2023

❓ Frequently Asked Questions

• What does FXBW-24-120 mean?
It denotes a composite suspension insulator rated for 24kV with 120kN mechanical strength.

• Can it replace porcelain insulators?
Yes, it offers better UV resistance, lighter weight, and higher pollution class performance.

• What fittings are available?
Ball-and-socket or clevis end fittings, customizable for different string configurations.

• Is it suitable for areas with frequent lightning?
Yes. Its hydrophobic surface and long creepage path reduce the chance of flashover.

• What’s the lead time?
Standard orders ship in 7–15 days depending on quantity.

📞 Talk to an Insulator Expert

Thor – High Voltage Applications Engineer
📞 Phone: +86-0577-62788197
📱 WhatsApp: +86 159 5777 0984
📧 Email: [email protected]

From high-load mountainous lines to humid coastal regions, the FXBW-24-120 delivers durable, low-maintenance performance where traditional insulators fail.
