Product Overview

The JBK Series Custom Manual Multi-Tap Control Transformer is specially designed for industrial machine tools and automation equipment. It accurately converts 120V input voltage into stable 24V control power while supporting manual tap adjustment and custom voltage configurations.

Widely used in North American standard machine tools, imported equipment retrofits, automation control cabinets, and industrial control systems, the transformer provides safe, stable, and reliable low-voltage power for industrial control circuits.

This 75VA model is ideal for small control loads such as relays, indicator lights, solenoid valves, and signal circuits.

Key Features

Manual Multi-Tap Design for Flexible Voltage Adjustment

The transformer features a manual multi-tap terminal design, allowing users to adjust wiring terminals according to actual input voltage conditions.

Advantages include:

• Easy voltage fine-tuning

• Better adaptation to unstable grid voltage

• No additional voltage stabilizer required

• Flexible field installation

• Convenient wiring adjustment

Both input and output voltages can be custom-designed for different industrial applications.

In addition to 120V to 24V models, other voltage combinations are available for:

• Machine tools

• Automation equipment

• Imported machinery retrofits

• Industrial control cabinets

100% Pure Copper Winding

The transformer adopts a full copper winding with high conductivity and low resistance, ensuring reliable long-term operation.

Benefits:

• Lower temperature rise

• Better electrical conductivity

• Strong anti-aging performance

• Longer service life

• Reduced risk of overheating

The winding is coated with high-temperature insulation varnish to improve insulation performance and reduce leakage and short-circuit risks.

High-Quality Silicon Steel Core

The core is made of premium high magnetic flux silicon steel laminations with tightly stacked construction for low magnetic loss and efficient operation.

Advantages:

• Efficiency above 85%

• Low operating noise

• Reduced heat generation

• Stable long-term performance

• Energy-saving operation

The durable silicon steel core also offers excellent resistance to vibration and industrial impact environments.

Designed for Industrial Working Conditions

The JBK Series is suitable for demanding industrial environments and continuous operation.

Operating conditions:

• Ambient temperature up to +40℃

• Relative humidity ≤95%

• Altitude ≤2000m

Features:

• Dry-type natural cooling

• Open structure with excellent ventilation

• Stable operation under humid and dusty environments

• Suitable for long-term industrial use

The transformer is designed for environments without corrosive gases or conductive dust.

Wide Range of Applications

The JBK manual multi-tap control transformer is widely used for:

• Machine tools

• Industrial machinery

• Automation control cabinets

• Relay control systems

• Indicator light circuits

• Solenoid valves

• Instrument equipment

• Small control boxes

• Signal circuits

It provides stable and clean low-voltage power for various industrial control loads.

Technical Specifications

Why Choose JBK Series Control Transformers?

• Manual multi-tap voltage adjustment

• Genuine 100% copper winding

• Compact 75VA design for small control circuits

• Stable 120V to 24V conversion

• Durable silicon steel core

• Reliable industrial performance

• Flexible custom voltage support

• Suitable for machine tools and automation systems

Custom Service

We provide custom solutions, including:

• Input/output voltage

• VA capacity

• Multi-tap configuration

• Terminal arrangement

• Mounting structure

• OEM branding

Contact us for technical support, product drawings, and custom transformer solutions.
